3. Press RESET to cancel the message, or RESET-ALL to cancel all error
messages.
4. Press HOME to leave the menu and to return to the home menu.
To analyse dimmer status and performance
1. Select INSTALL from the home screen
2. Press DOWN or UP or use the rotary encoder to choose VIEW CHANNEL
DATA menu. Press SELECT.
3. The screen shows:
LIVE CHANNEL DATA DEVICE 12
CH I. U. T. DMX-1 DMX-2 ACTUAL STAT.
01 22 232 027 128 099 128 OK
CH- CH+ DEV- DEV+ HOME
where:
I = current measured at the output
U = voltage at the input of the dimmer
T = dimmer module temperature
DMX-1 and -2 = DMX levels received
ACTUAL = the level the dimmer is responding to
STAT = either OK, or error message(s) with letter codes as above
4. Press CH+ or CH- to display channels in sequence, and DEV+ and DEV- to
display devices in sequence.
5. Press HOME to leave the menu and to return to the home menu.
Matrix OS software
Matrix Mk.II operating system software comprises three sections: processor, Ethernet
merger and Matrix devices.
CAUTION: this section is for the use of service technicians and should only be accessed or
updated under instruction from a qualified technician.
To check dimmer software version
1. Select INSTALL from the home menu
2. Press DOWN or UP or use the rotary encoder to choose SYSTEM
INFORMATION menu. Press SELECT.
3. The screen shows:
