General settings
This is the main system menu for general operating features:
•
DMX address settings [individual or joined]
•
Channel configuration settings [individual or joined]
•
DMX 1 fail [reset, hold or backup]
•
DMX 2 fail [reset, hold or backup]
• Sleep
mode [on/off]
•
Voltage regulation [on/off]
•
Current limitation [on/off]
•
DMX Minimum reset [on/off]
•
Erase all presets [yes/no]
•
DMX lamp saver [on/off]
•
DMX lamp tuning [on/off]
Load selection
This sets the number of dimmers and their rating per module.
Line voltage calibration
This sets the nominal voltage for L1, L2, L3.
Return to factory settings
Resets the channel parameters to the default levels.
View channel data
This gives a summary of present operating conditions of each channel. Channel
number, current, voltage, temperature, DMX A level, DMX B level, actual DMX level
used, status of channel (OK or fault).
System info
Gives a list of software versions in use, and provides technicians with data frame
counts to facilitate fault finding.
Firmware update
Allows a suitably trained technician to update the firmware for all dimmers, selected
dimmers or the merger.
Ethernet set up
This menu is to set the IP address, subnet mask and gateway address for the rack.
Merger Ethernet set up
This menu is to set the IP address, subnet mask, gateway address and Net universe
A and B for the processor's merger.
Blower test
The facility for checking ventilation within the rack. Either all fans or selected fans can
be controlled to test efficiency.
F5 INFO
This menu provides the software settings of the processor, or if a fault is reported, it
provides details and reset options.
