BIOS CONFIGURATION
60
set. If multiple volume sets reside on a specified RAID set, all
volume sets will reside on all physical disks in the RAID set. Thus
each volume set on the RAID set will have its data spread evenly
across all the disks in the RAID set rather than one volume set
using some of the available disks and another volume set using
other disks.
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
Hdd Power Management
Ethernet Configuration
View System Events
Clear Event Buffer
Hardware Monitor
System information
Volume Set Function
The following is the volume set features for the SAS RAID con-
troller.
1. Volume sets of different RAID levels may coexist on the same
RAID set.
2. Up to 128 volume sets can be created in a RAID set.
3. The maximum addressable size of a single volume set is not
limited to 2TB, because the controller is capable of 64-bit
LBA mode. However the operating system itself may not be
capable of addressing more than 2TB.
See Areca website ftp://ftp.areca.com.tw/RaidCards/Docu-
ments/Manual_Spec/ Over2TB_050721.ZIP file for details.
