INTRODUCTION
15
SAS RAID card
Model name ARC-1680ix-8 ARC-1680IXL-12 ARC-1680 IXL -16
I/O Processor Intel IOP348 1200MHz
Form Factor 69(H) x 210(L) mm 69(H) x 240(L) mm
Host Bus Type PCIe x8 Lanes
Driver Connector 2xSFF-8087
1xSFF-8088
3xSFF-8087
1xSFF-8088
4xSFF-8087
1xSFF-8088
Drive Support Up to 128 SAS/SATA HDDs
RAID Level 0, 1, 10(1E), 3, 5, 6, 30, 50, 60, Single Disk, JBOD
On-Board Cache 512MB on-board DDR2-533 SDRAM
Management
Port In-Band: PCIe
Out-of-Band: BIOS, LCD, LAN Port
Enclosure
Ready Individual Activity/Faulty Header, SGPIO, SMP,
SES2 (For External Port)
Note:
*1: IOP348 speed from 800MHz to 1200MHz
(ARC-1680i/LP: version 1.0. ARC-1680x: version 2.0)
*2: On-Board Cache 256MB to 512MB
(ARC-1680i/LP: version 1.0. ARC-1680x: version 2.0)
