HARDWARE INSTALLATION
36
Figure 2-17, ARC-1680LP
individual LED for each channel
drive and global indicator
connector for computer case.
Figure 2-18, ARC-1680i
individual LED for each channel
drive and global indicator
connector for computer case.
Figure 2-19, ARC-1680IXL-
12/16 individual LED for
each channel drive and
global indicator connector for
computer case.
