Using Set-Up Mode

5-8

Select the Macro 2 function.
Wait for the printer to stop printing. Then press the

button once to position

the red cursor on the plastic guide of the print head under MACRO 2. Press the

button or the button to select the Macro 2 function and print the

COL> option and its values.

Print the menu of the left margin option.
Since you only want to change the left margin, press the button to select the
current protocol. The bolded PORT DEPND is underlined, and the next option
is printed. (The bolded value indicates the current setting, and
the underlined value is the new setting.) Repeatedly press the button until the
option and its value are printed.

Change the left margin from column 1 to column 20.
Press and hold the

button until the printer beeps nineteen times. When the

button is released, the new value is printed next to the current value. If the new
value is not 20 COL, repeat this operation. If it is 20 COL, press thebutton to
select 20 COL. 20 COL is underlined, and the next option, ,
and its value are printed.

Exit the Macro 2 function.
Since you do not want to make any other changes in MACRO 2, press the Exit/
Save button. The menu is then reprinted, and the red cursor is
positioned beneath SAVE&EXIT.

Exit the Set-Up mode, saving or not saving the new left margin.
Press the button or the button to save 20 columns as the new power-on
default in Macro 2 and exit Macro 2. The printer then exits the Set-Up mode and
returns to the Ready state. These settings remain in effect until the next time they
are changed.
Press the Set-Up/Quit button if you do not intend saving these settings in
Macro 2.

Options with Both Pre-determined and Undetermined Values

Some options include both types of values. Undetermined values appear at the end
of the list of pre-determined values, identified by the unit of the corresponding range.

For example, when you select the
