Printer and Paper Specifications
B-5
Paper Specifications
Print Area
This section illustrates the recommended print area for single sheets and continuous
forms.
Print area for single sheets
May be decreased
to 4.23 mm
(1/6 inch).
However, line
spacing may be
uneven.
May be decreased to
4.23 mm
(1/6 inch).
However, line spacing
may be uneven.
Print area may be off
the paper, depending
on paper setting or
width.
25.4 mm (1 inch)
25.4 mm (1 inch)
Print area
5.08 mm or more
(0.2 inch or more)
H H
H H
102-266.7 mm (4-10.5 in)
for 80-column printer
102-420 mm (4-16.5 in)
for 136-column printer
76-364 mm (3-14.3 in)
for 80-column printer
76-420 mm (3-16.5 in)
for 136-column printer
5.08–32 mm (0.2–1.26 in)
for 80-column printer
5.08-38 mm (0.2-1.5 in)
for 136-colimn printer
