Technical specifications
Eppendorf SOP
English (EN)
9.3.5 Xplorer and Xplorer plus
pipette
Increment Pipette tip
Color code
Volume range
Length Testing
volume Error limits
Error
Systematic
error
Random error
µL µL % µL % µL
0.5 μL – 10 μL
Increment:
0.01 μL Medium gray
0.1 μL – 20 μL
40 mm 1 μL ±5.0 ±0.05 ±3.0 ±0.03
5 μL ±3.0 ±0.15 ±1.5 ±0.075
10 μL ±2.0 ±0.2 ±0.8 ±0.08
5 μL – 100 μL
Increment:
0.1 μL Yellow
2 μL –200 μL
53 mm 10 μL ±2.0 ±0.2 ±2.0 ±0.2
50 μL ±1.0 ±0.5 ±0.8 ±0.4
100 μL ±0.8 ±0.8 ±0.25 ±0.25
15 μL – 300 μL
Increment:
0.2 μL Orange
15 μL –300 μL
55 mm 30 μL ±2.5 ±0.75 ±1.0 ±0.3
150 μL ±1.0 ±1.5 ±0.5 ±0.75
300 μL ±0.6 ±1.8 ±0.25 ±0.75
50 μL – 1200 μL
Increment:
1 μL Green
50 μL–1250 μL
76 mm 120 μL ±6.0 ±7.2 ±0.9 ±1.08
600 μL ±2.7 ±16.2 ±0.4 ±2.4
1200 μL ±1.2 ±14.2 ±0.3 ±3.6
