Eppendorf SOP - Manual (Page 46)

46
Technical specifications
Eppendorf SOP
English (EN)
9.2.5 Research plus adjustable-volume
Research plus adjustable single-channel
Model Test tip
epT.I.P.S. Color code
Volume range
Length Testing
volume Eppendorf AG error limits
Error
Systematic
error
Random
error
± % ± µL ± % ± µL
0.1 μL – 2.5 μL
Increment:
0.002 μL Dark gray
0.1 μL – 10 μL
34 mm 0.1 μL ±48 ±0.048 ±12 ±0.012
0.25 μL ±12 ±0.03 ±6.0 ±0.015
1.25 μL ±2.5 ±0.031 ±1.5 ±0.019
2.5 μL ±1.4 ±0.035 ±0.7 ±0.018
0.5 μL – 10 μL
Increment:
0.01 μL Medium gray
0.1 μL – 20 μL
40 mm 0.5 μL ±8.0 ±0.04 ±5.0 ±0.025
1 μL ±2.5 ±0.025 ±1.8 ±0.018
5 μL ±1.5 ±0.075 ±0.8 ±0.04
10 μL ±1.0 ±0.1 ±0.4 ±0.04
2 μL – 20 μL
Increment:
0.02 μL light gray
0.5 μL – 20 μL L
46 mm 2 μL ±5.0 ±0.1 ±1.5 ±0.03
10 μL ±1.2 ±0.12 ±0.6 ±0.06
20 μL ±1.0 ±0.2 ±0.3 ±0.06
2 μL – 20 μL
Increment:
0.02 μL Yellow
2 μL - 200 μL
53 mm 2 μL ±5.0 ±0.1 ±1.5 ±0.03
10 μL ±1.2 ±0.12 ±0.6 ±0.06
20 μL ±1.0 ±0.2 ±0.3 ±0.06
10 μμL – 100 μL
Increment:
0.1 μL Yellow
2 μL - 200 μL
53 mm 10 μL ±3.0 ±0.3 ±1.0 ±0.1
50 μL ±1.0 ±0.5 ±0.3 ±0.15
100 μL ±0.8 ±0.8 ±0.2 ±0.2
20 μL - 200 μL
Increment:
0.2 μL Yellow
2 μL - 200 μL
53 mm 20 μL ±2.5 ±0.5 ±0.7 ±0.14
100 μL ±1.0 ±1.0 ±0.3 ±0.3
200 μL ±0.6 ±1.2 ±0.2 ±0.4
30 μL – 300 μL
Increment:
0.2 μL Orange
20 μL – 300 μL
55 mm 30 μL ±2.5 ±0.75 ±0.7 ±0.21
150 μL ±1.0 ±1.5 ±0.3 ±0.45
300 μL ±0.6 ±1.8 ±0.2 ±0.6
100 μL – 1 000 μL
Increment:
1 μL Blue
50 μL – 1 000 μL
71 mm 100 μL ±3.0 ±3.0 ±0.6 ±0.6
500 μL ±1.0 ±5.0 ±0.2 ±1.0
1,000 μL ±0.6 ±6.0 ±0.2 ±2.0
