Eppendorf SOP - Manual (Page 52)

52
Technical specifications
Eppendorf SOP
English (EN)
9.3.4 Reference2
Reference2 Variable multi-channel (8-channel/12-channel)
Model Test tip
epT.I.P.S. Color code
Volume range
Length Testing
volume Eppendorf AG error limits
Error
Systematic
error
Random
error
± % ± µL ± % ± µL
0.5 μL – 10 μL Medium gray
0.1 μL – 20 μL
40 mm 0.5 μL ±12.0 ±0.06 ±8.0 ±0.04
1 μL ±8.0 ±0.08 ±5.0 ±0.05
5 μL ±4.0 ±0.2 ±2.0 ±0.1
10 μL ±2.0 ±0.2 ±1.0 ±0.1
10 μL – 100 μL Yellow
2 μL - 200 μL
53 mm 10 μL ±3.0 ±0.3 ±2.0 ±0.2
50 μL ±1.0 ±0.5 ±0.8 ±0.4
100 μL ±0.8 ±0.8 ±0.3 ±0.3
30 μL – 300 μL Orange
20 μL – 300 μL
55 mm 30 μL ±3.0 ±0.9 ±1.0 ±0.3
150 μL ±1.0 ±1.5 ±0.5 ±0.75
300 μL ±0.6 ±1.8 ±0.3 ±0.9
