Eppendorf SOP - Manual (Page 45)

45
Technical specifications
Eppendorf SOP
English (EN)
9.2.4 Research pro
Model Test tip
epT.I.P.S. Color code
Volume range
Length Testing
volume Error limits
Error
Systematic
error
Random
error
± % ± µL ± % ± µL
0.5 - 10 μL light gray
0.5 – 20 μL L
46 mm 1 μL ±2.5 ±0.025 ±1.8 ±0.018
5 μL ±1.5 ±0.075 ±0.8 ±0.04
10 μL ±1.0 ±0.1 ±0.4 ±0.04
5 - 100 μL Yellow
2 - 200 μL
53 mm 10 μL ±2.0 ±0.2 ±1.0 ±0.1
50 μL ±1.0 ±0.5 ±0.3 ±0.15
100 μL ±0.8 ±0.8 ±0.2 ±0.2
20 – 300 μL Orange
20 – 300 μL
55 mm 30 μL ±2.5 ±0.75 ±0.7 ±0.21
150 μL ±1.0 ±1.5 ±0.3 ±0.45
300 μL ±0.6 ±1.8 ±0.2 ±0.6
50 - 1 000 μL Blue
50 - 1 000 μL
71 mm 100 μL ±3.0 ±3.0 ±0.6 ±0.6
500 μL ±1.0 ±5.0 ±0.2 ±1.0
1,000 μL ±0.6 ±6.0 ±0.2 ±2.0
500 – 5 000 μL Purple
0.1 – 5 mL
120 mm 0.5 mL ±3.0 ±15 ±0.6 ±3.0
2.5 mL ±1.2 ±30 ±0.25 ±6.25
5.0 mL ±0.6 ±30 ±0.15 ±7.5
