94 Brocade Adapters Administrator’s Guide
53-1001256-01
Eth Statistics dialog box (CNA only)
A
Eth Statistics dialog box (CNA only)
The Eth Statistics dialog box enables you to display statistical information related to the Ethernet
port.
Opening the dialog box
1. Select an Ethernet port from the device tree.
2. Select Monitor > Statistics > Eth Statistics from the main menu.
OR
Right-click the Ethernet port and select Statistics > Eth Statistics from the list.
The Eth Statistics dialog at the host level displays.
Fields and components
Field Description
Keep Running Data checkbox Click to continue running statistical data. This is useful if you want to
see a trend.
Polling Frequency in Seconds text box Type a number for polling frequency. The range is between five and
3600 seconds and the default is five seconds.
Start Polling button Click to manually poll the Ethernet IOC statistics.
Reset button Click to reset all of the statistics to 0.
Date The date the Eth statistics were run.
Txf0 Unicast Octets Total number of transmitted unicast octets.
Txf0 Unicast Total number of transmitted unicast frames.
Txf0 Unicast Vlan Total number of transmitted unicast VLANs.
Txf0 Multicast Octets Total number of transmitted multicast octets.
Txf0 Multicast Total number of transmitted multicast frames.
Txf0 Multicast Vlan Total number of transmitted multicast VLANs.
Txfo Broadcast Octets Total number of transmitted broadcast octets.
Txf0 Broadcast Total number of transmitted broadcast frames.
Txf0 Broadcast Vlan Total number of transmitted broadcast VLANs.
Txf0 Errors Total number of transmitted errors.
Txf0 Filter Vlan Total number of transmitted VLAN filters.
Txf0 Filter MAC SA Total number of transmitted filter MAC source addresses.
Rxf0 Unicast Octets Total number of received unicast octets.
Rxf0 Unicast Total number of received unicast frames.
Rxf0 Unicast Vlan Total number of received unicast VLANs.
Rxf0 Multicast Octets Total number of received multicast octets.
Rxf0 Multicast Total number of received multicast frames.
