SwitchBlade x8112 Chassis Switch Installation Guide
51
The wiring configuration of the NET MGMT port is set automatically with
automatic MDIX detection. You may disable automatic MDIX detection
and set the wiring configuration manually.
NET MGMT
LED
The Network Management (NET MGMT) port on the AT-SBx81CFC400
Controller Fabric Card has one Status LED, described in Table 13.
Console (RS-232)
Port
The Console Port is used to conduct local management sessions with the
switch. Local management sessions are established with a terminal or PC
with a terminal emulation program, and the management cable that comes
with the card.
Local management is referred to as out-of-band management because it
is not conducted over a network. Consequently, the AT-SBx81CFC400
Controller Fabric Card does not need an Internet Protocol (IP) address for
this type of management.
Your initial management session with the switch must be a local
management session. For instructions on how to start a local management
session, refer to “Using Local Management to Verify the Chassis” on
page 182 or the Software Reference for SwitchBlade x8100 Series
Switches.
USB Port
The USB port supports a flash drive. You may use a flash drive to perform
the following management functions:
 Store backup copies of the master configuration and database files
on the AT-SBx81CFC400 Controller Fabric Card.
 Transfer master configuration files between controller cards in
different chassis that are to have similar configurations.
 Transfer application load files between controller cards.
 Store streaming log files.
Table 13. NET MGMT Port LED
LED State Description
L/A
Solid Green The port has a valid 1000 Mbps link.
Flashing
Green The port is transmitting or receiving data at
1000 Mbps.
Solid Amber The port has a valid 10 or 100 Mbps link.
Flashing
Amber The port is transmitting or receiving data at
10 or 100 Mbps.
Off The port has not established a link to a
network device.
