As shown in figure – Allied Telesis SwitchBlade x8112 User Manual
Page 133
SwitchBlade x8112 Chassis Switch Installation Guide
133
Figure 86. Handle on SFP+ Transceiver
3. Slide the transceiver into the slot until it clicks into place, as shown in
Figure 87. Installing an SFP+ Transceiver in the AT-SBx81XS6 Line Card
Note
If you are ready to attach the fiber optic cable to the transceiver,
continue with the next step. Otherwise, repeat steps 1 to 3 to install
the remaining SFP transceivers in the line cards.
Handle
