19
Chapter 1
Overview
This chapter describes the Layer 3+ SwitchBlade x8112 Chassis Switch in
the following sections:
 “Introduction” on page 20
 “AT-SBx8112 Chassis” on page 23
 “AT-SBx81GT24 Line Card” on page 27
 “AT-SBx81GT40 Line Card” on page 28
 “AT-SBx81GP24 PoE Line Card” on page 29
 “AT-SBx81GS24a SFP Line Card” on page 30
 “AT-SBx81XS6 SFP+ Line Card” on page 31
 “10/100/1000Base-T Twisted Pair Ports” on page 32
 “Power over Ethernet on the AT-SBx81GP24 Line Card” on page 35
 “Port LEDs on the Ethernet Line Cards” on page 38
 “AT-SBx81CFC400 Controller Fabric Card” on page 44
 “AT-SBxPWRSYS1 Power Supply” on page 53
 “AT-SBxPWRPOE1 Power Supply” on page 55
 “AT-SBxPWRSYS1 DC Power Supply” on page 57
 “AT-SBxFAN12 Module” on page 59
 “Power Supply Interfaces (Opto-couplers)” on page 60
 “AlliedWare Plus Software Releases for the Hardware Components” on
page 61
Note
This version of the installation guide applies to release 5.4.3 of the
AlliedWare Plus Operating System for the SwitchBlade x8112
Chassis Switch.
