Chapter 6: Installing the Transceivers and Cabling the Ports

138

4. Install the other end of the cable into an SFP+ slot on another network

device.

5. Repeat this procedure to install additional AT-SP10TW Cables.

Note

To remove the connector and cable from the SFP+ slot, gently push
on the connector, pull on the release tab, and then slide the
connector from the slot.

After installing the AT-SP10TW Cables in the AT-SBx81XS6 Line Card, do
one of the following:

To install and cable additional transceivers, go to the appropriate
section in this chapter for instructions.

After cabling all the ports in the chassis, go to Chapter 7,
“Powering On the Chassis” on page 141.
