SwitchBlade x8112 Chassis Switch Installation Guide
137
Note
Do not remove the dust plug from the SFP+ slot if you are not
installing the transceiver at this time. The dust plug protects the line
card from dust contamination.
2. Orient the connector on the AT-SP10TW cable so that the release tab
is on top, as shown in Figure 91.
Figure 91. Release Tab on the AT-SBx81XS6 Line Card
3. Slide the connector into the slot until it clicks into place, as shown in
Figure 92. Installing the AT-SP10TW Cable in the AT-SBx81XS6 Line
Card
