Samsung SGH-I527ZKBATT User Manual

Page 14

• Make sure that the card’s gold contacts face into the phone

and that the upper-left angled corner of the card is positioned

as shown.

Note: If the card is not inserted correctly, the phone will not

detect the SIM card. Re-orient the card back into the slot
if the SIM is not detected.

2. To insert a MicroSD card (optional), carefully slide the

MicroSD card under the top metal plate into the

MicroSD card socket (as shown) until the card locks

into place.

Installing the Battery

1. Insert the battery into the opening on the back of the

phone, making sure the connectors align (1).

2. Gently press down to secure the battery (2).

Installing the Back Cover

1. Place the battery cover onto the back of the phone (1)

and press down (2).
