SECTION 1. FUNCTIONAL MODES
1-10
TABLE 1.6-1. Description of
B
Mode Data
Keyboard
Display ID:
Entry
Data
Description of Data
∗
B
01:
Program memory Signature. The value is dependent upon the
+XXXXX
programming entered and memory allotment. If the program has
not been previously compiled, it will be compiled and run.
A
02:
Operating System (OS) Signature
+XXXXX
A
03:
Memory Size, Kbytes (Flash + SRAM). "--" indicates that a full
XXXXX
memory reset was aborted.
A
04:
Number of E08 occurrences (Key in 88 to reset)
XX
A
05:
Number of table overrun occurrences (Key in 88 to reset)
XX
A
06:
Operating System version number
+X.XXXX
A
07:
Version revision number
XXXX.
A
08:
Lithium battery voltage (measured daily)
+X.XXXX
A
09:
Low 12 V battery detect counter (Key in 88 to reset)
XX
A
10:
Extended memory error counter (Key in 88 to reset)
XX
A
11:
Extended Memory time of erase, seconds. If >5 at room
+X.XXXX
temperature, flash memory may be wearing out. Contact CSI
for replacement information.
A
12:
Low 5 V counter (Key 88 to reset)
XX
A
13:
Program Time (0.407
µ
sec resolution, range is 6.826 seconds,
+X.XXXX
above 6.826, time = 6.826 + displayed value)
A
14:
Panel Temperature (updated at least every 1 to 2.8 minutes)
+X.XXXX
A
15:
Coprocessor Revision
XX
A
16:
Coprocessor Status
XX
A
17:
CPLD Revision
XX
