CR23X INDEX

INDEX-2

BPALK Alkaline Power Supply 14-3
Bridge measurements 13-16

3 Wire Half Bridge 100 ohm PRT 7-5
4 Wire Full Bridge (Pressure Transducer)

7-7

4 Wire Full Bridge 100 ohm PRT 7-6
4 Wire Half Bridge 100 ohm PRT 7-4
6 Wire Full Bridge (Lysimeter) 7-8
Comparison of bridge measurement

instructions 13-18

Diagram of bridge measuring circuits

with AC excitation 13-17

Bridge Transform - [Instruction 59] 10-6

Programming examples 7-7, 7-10, 8-4

Bulk Load - [Instruction 65] 10-15

Programming example 7-21

Burst Measurement - [Instruction 23] 9-11

C

Cables/Leads

Avoid PVC insulated conductors 13-10
Connecting Leads to Wiring Panel OV-1
Effect of lead length on signal settling

time 13-4

Tipping bucket rain gage with long leads 7-4

Calibration - [Instruction 24] 9-14, 13-21
Case

Begin Case - [Instruction 93] 12-5
If Case 12-1

Cautionary notes x
CD16AC, see SDM-CD16AC AC/DC Relay

Controller

Channels

Differential analog OV-3, 13-2
Single-ended analog OV-3, 13-2

Checksum 5-2
Clear To Send (CTS) 6-6, B-1
Clock

Example of setting OV-19
Set/display time (

5

Mode) 1-4

CM6/CM10 Tripods grounding protection 14-6
COM200 Phone Modem 6-2, 12-7, G-1, H-2

Lightning Protection 14-5
Typical Current Drain 14-1

Common mode range 13-3, 14-7
Communicating with the CR23X OV-11

Via telemetry 5-1
With external peripherals 4-1
With other dataloggers H-1

Communication

Protocol OV-11, 5-1, 6-7
Troubleshooting 6-7

Compiling

Data 1-5
Errors 3-9
Program 1-3

Computation of Running Average 8-1, 10-4
Computer

Connecting to serial port OV-11
Save/load program (

D

Mode) 1-11

Use with SC32A OV-12, 6-5

Connecting Power to the CR23X OV-3, OV-5,

14-2

Control Port Expansion Module with Drivers,

see SDM-CD16AC

Control/Logic ports

Command codes affecting OV-4, 12-1
Configuration, see Port Set - [Instruction 20]
Description of OV-4
Displaying and Toggling 1-5, C-1
Indexing 3-1
Switch Closures, Measuring on Control

Ports 8-5, 9-1

Use of digital I/O ports for switching relays 14-7
Using control ports for RS-232 Input B-1
Voltages > 5.0, Applying x, 9-10

Control port serial I/O - [Instruction 15] 9-9, B-1

Programming examples B-1, B-9

Copy input location data to another location -

[Instruction 31] 10-1
Programming example 8-7, 8-13

Cosine 10-3
Counter

Add 1 to value in input location -

[Instruction 32] 10-1

Pulse, see Pulse Count - [Instruction 3]
Sending to 16 bit accumulator 9-2

COV/CORR, see Covariance/Correlation -

[Instruction 62]

Covariance Correlation - [Instruction 62] 10-11

Programming Example 8-11

CS500 Temp/RH Sensor 7-12
CSAT3, see SDM-CSAT3
CSM1 Card Storage Module, see Storage

Modules

CTS (Clear To Send) 6-6, B-1
Current drain of standard peripherals 14-1
CURS100 Terminal Input Module 7-22

D

Data Carrier Detect (DCD) 6-6
Data point

Definition A-1
Number per Output Array 4-3
