Chapter 5 ____________________________________________________________ Technical Data
VAISALA______________________________________________________________________ 149
Ethernet Communication Module DSE101
The Ethernet communication module DSE101 provides a 10base-T
connection, which is compatible with 100 Mbps and 1 G switches;
DSE101, however, operates at 10 Mbps. Supported by software, the
module allows virtual serial port connections and socket connections to
be established to the logger.
1003-031
Figure 72
Ethernet Communication Module DSE101 Wiring
Diagram
Table 37
Ethernet Communication Module DSE101
Specifications
Property
Description/value
Operating mode
10Base-T
Power consumption
(transmitting)
50 mA at 12V
Temperature
Normal: -40 ... +70 °C (-76 ... +158 °F)
Extended: -60 ... +70 °C (-76 ... +158 °F)
Humidity
0 ... 100% RH
