Chapter 4 ___________________________________________________________ Troubleshooting
VAISALA______________________________________________________________________ 121
Table 26 Parameters for the Open Command
Connector in Lizard Parameter Alias
COM0 COM0 COM0
COM1 COM1 COM1
DMX501 (MOD1/1) DMX501_0 MOD1
DMX501 (MOD2/1) DMX501_1 MOD2
DSI485A (MOD1/1) DSI485_0 MOD1
DSI485A (MOD2/1) DSI485_1 MOD2
DSI486 (MOD1/1) DSI485_0_0 MOD1_2
DSI486 (MOD1/2)
DSI486_0_1
1
1. With the dual RS-485 module, the RS-232 connection is possible only to
the channel B on the module, and thus the last number is 1.
MOD1_1
DSI486 (MOD2/1) DSI486_1_0 MOD2_2
DSI486 (MOD2/2)
DSI486_1_1
1 MOD2_1
DSI486SDI (MOD1/3) DSI486SDI_0 MOD1_3
DSI486SDI (MOD2/3) DSI486SDI_1 MOD2_3
DSU232 (MOD1/1)
DSU232_0_0 2
2. With the RS-232 and dual RS-485 modules, the number between the
underline characters stands for the module place, that is, MOD1 or MOD2,
and the last number for the channel on that particular module.
MOD1_1
DSU232 (MOD1/2) DSU232_0_1 MOD1_2
DSU232 (MOD2/1) DSU232_1_0 MOD2_1
DSU232 (MOD2/2) DSU232_1_1 MOD2_2
DSU232SDI (MOD1/3) DSU232SDI_0 MOD1_3
DSU232SDI (MOD2/3) DSU232SDI_1 MOD2_3
NOTE Use the SYSINFO PORTS command to find out which connectors to
use.
