44 Radio Option Kits
Antenna Installation Procedure
Antenna Installation Procedure
1. Flip the Roof Module back into the upright position.
2. Attach the required whip antennas to the proper Roof Module antenna connections. See Figure 4-48.
Note: A threaded plastic NMO cap is provided to protect the VHF/UHF antenna base when the whip antenna is not
installed. Always install the NMO cap when transporting or shipping the ParaDyme system without a VHF/UHF
antenna.
Note: Hand tighten the connections to ensure a good waterproof seal and electrical continuity. Do not over tighten.
Note: Figure 4-48 shows the location of the three possible antennas. Roof Modules with Part Number 200-0473-02 or
earlier have a WiFi antenna that needs to be installed. Roof Modules with Part Number 200-0473-03 and later no
longer have this antenna and instructions pertaining to it can be ignored.
Note: Make sure the antenna O-ring seats properly in its groove and does not get squeezed between the antenna base
and the Roof Module extrusion. See Figure 4-49.
WARNING
To avoid electrical shock hazards, remove the Roof Module
from the vehicle before driving under low structures or low
electrical power lines.
