Hardware Installation Guide 27
900 MHz RTK Radio Modem Kit Installation Procedure (200-0505-04 Kit)
6. Attach the bulkhead adapter connector of the internal coax cable to the housing of the ParaDyme Smart Antenna.
Note: Verify that the lock washer is on the outside of the housing before attaching the nut. Do not tighten the
connector at this time.
Figure 4-19 Attach Internal Coax Cable to Housing
7. Locate the Freewave MM2 mounting position on the circuit board and the four screw attachment points. See Figure 4-20.
Figure 4-20 900 MHz Radio Modem Installation Location
Internal Coax Cable Attached
