28 Radio Option Kits
900 MHz RTK Radio Modem Kit Installation Procedure (200-0505-04 Kit)
8. Place four spacers on top of the existing screw holes.
Figure 4-21 Install Spacers
9. Align the 900 MHz radio modem and insert the pins into the J3 header as shown in Figure 4-22.
Note: Exercise care when installing the 900 MHz radio. The pins in the connector must be properly aligned and not
bent during the installation. Failure to line up the pins could cause damage to the circuit board and invalidate the
warranty.
Figure 4-22 Verify Pins Line up when Attaching 900 MHz Circuit Board
Spacers
