36 Radio Option Kits
UHF and VHF Radio Modem Kit Installation Procedure
9. Mount the UHF or VHF radio and bracket on the ParaDyme receiver with four M3 x 5mm screws. Torque the screws to 5
in-lb (0.6 Newton meters) with a #1 Phillips screwdriver. See Figure 4-36.
Figure 4-36 UHF or VHF Radio Modem Installed
10. Attach the ribbon cable to the UHF or VHF Radio Modem with two 4/40 x 3/8 screws. Torque the screws to 5 in-lb (0.6
Newton meters) with a #1 Phillips screwdriver.
Figure 4-37 UHF or VHF Radio Modem Installed
Attach with Screws
Attach with Screws
