Press: Home button > Setup (wrench) button > Configuration (tractor) button > Configuration tab > Your
Specific Configuration > Setup (wrench) button
Note: Use the Manage Equipment button to view a list of specific vehicles and implements.
I
MPLEMENT
O
FFSETS
Press
to adjust vehicle offsets.
Press:
to modify source of speed.
Press
to adjust plow offsets
that were setup when creating configuration.
Antenna to Tip is the horizontal measurement of the
tip to the Antenna. An example is if the tip is 24
inches front of the Antenna, you would enter 24 in.
and Front (as shown).
Configuration
Select Your Specific
Configuration
Configuration Setup
Vehicle
JD 8530
Implement: SoilMax Golddigger
ul Swath:
Sections:
32808 ft
1
Controller: tile
Serial Number
Unassigned
Offsets
Vehicle
Offsets
Controller
Settings
Speed
Input
Equipment
Settings
Vehicle Offsets
Speed Input
Offsets
