"/". Next, specify any contiguous range of device address, and then press the
F6=Scan key to discover HP storage systems and devices.
Device Num ( ) | Start: 7310 End: 731F
Volser ( ) | Start:
End:
------------------------------------------------------------------------------
Non Gen'ed ( / )
Supported action: s(Select)
AC
Non Gen'ed Device Address Domain . . DADP.NG
Storage System S/N . . . . . . . . . 12345
Device Address | Start CU: 00 CCA: 00
| End CU: 00 CCA: FF
F1=Help F3=Exit F6=Scan F7=Backward F8=Forward F12=Cancel
11.
Press the F6=Scan key.
NOTE:
When using a command device during an NG scan, in the Set Defaults panel, specify
Y
for Remote DKC Function, and the route list of the first entry for the storage system subject
to the NG scan for Preset RouteListID.
An NG scan is performed and the CU Selection List for Edit devn panel is displayed.
CU Selection List for Edit devn Row 1 to 1 of 1
Command ===>
Scroll ===> PAGE
2008/03/19 15:04:44
Supported actions: s(Select), e(Edit devn)
Device Address Domain : DADP.NG
Description . . . : DISCOVERED-NONGEN-STORAGE
Storage System S/N : 12345 Model : USPV uCode : 600243FF IFType : 2121
Software Keys CA( Y ) CAA ( Y ) BC ( Y ) CAJ ( Y )
------------------------------------------------------------------------------
AC CU SSID Dummy Devn Information
00 6800 NOTSET
******************************* Bottom of data ********************************
F1=Help F3=Exit F7=Backward F8=Forward F12=Cancel
12.
Assign a dummy device number.
For details on how to assign a dummy device number, see
“Assigning a dummy device number”
.
When a dummy device number is assigned, the Scan Device Address Extent panel is displayed
(NG scan is completed).
13.
Repeat steps 6 and 10 through 12 to perform a scan with another scope.
14.
Press the F3=Exit key.
The Discover HP Storage Arrays panel appears.
The Description setting values can be changed. You can change the dummy device number
that has already been assigned to the NG scan target storage system, indicated by a percent
sign (%) next to the storage system serial number.
Creating a path set
Defining the inter-DKC logical path set
This section explains how to define the inter-disk controller logical path, using the inter-disk controller
logical path definition example shown in
