Hardware View 73
Mo
ni
to
ri
n
g
a
n
d
Ma
na
g
ing
t
h
e D
ir
e
ct
o
r
• Unblock All Ports
Select this option to display the Unblock All Ports dialog box. Click Yes to unblock all
ports on the selected card or No to cancel.
• Diagnostics
Select this option to display the Port Diagnostics dialog box. Use this dialog box to run
internal loopback and external loopback tests on any port or all ports on the FPM card.
Refer to the hp surestore director fc-64 Installation and Service Manual (HP A6534-
90902) for instructions on using these diagnostics.
Port Menu
While in the Port Card View, right-click on any port to display the following menu options:
Port Properties
Click this to display the Port Properties dialog box. This dialog box displays information
about the port. See Displaying Port Information on page 68 for more information.
Node Properties
Click this to display the Node Properties dialog box. Note that if a node is not logged into
the port, a message appears indicating that node information is not available. For details on
information that displays in this dialog box, refer to Displaying Node Properties on page 87.
Port Technology
Click this to display the Port Technology dialog box. This dialog box displays the following
information:
• Port number
• Connector type: Always LC.
• Transceiver type: Longwave laser LC or shortwave laser LC.
• Distance: General distance range for port transmission. This can be either short to long
distances for the longwave laser LC transceiver or short distances for the shortwave
laser LC transceivers.
