HP Surestore 64 Director Switch - Manual (Page 85)

Hardware View 69
Mo
ni
to
ri
n
g
a
n
d
Ma
na
g
ing
t
h
e D
ir
e
ct
o
r
Figure 26 Port Properties Dialog Box
The following paragraphs describe the fields in the Port Properties dialog box.
• Port Number
The physical port number.
• Port Name
User-defined port name or description. Refer to Configure Ports on page 115 for
instructions.
• Type
– G_port. This displays if nothing is logged into the port.
– F_Port. This displays if a device is logged into the port.
– E_Port. This displays if the port is connected to another director’s E_Port via an ISL.
• Fibre Channel Address
The port’s Fibre Channel address identifier.
