Performance View 91
Mo
ni
to
ri
n
g
a
n
d
Ma
na
g
ing
t
h
e D
ir
e
ct
o
r
on a row in the Port List View. Refer to Port Menu on page 73 for an explanation of these
menu options.
• Port Properties
• Node Properties
• Port Technology
• Block Port
• Enable Beaconing
• Diagnostics
• Clear Link Incident Alert(s)
• Reset Port
• WWN Binding
• Clear Threshold Alert(s)
For Node Properties, if a node is not logged in a message displays indicating that node
information is not available.
Bar Graph Display
The Performance View provides a graphical display of performance for all ports. Each bar
graph in the upper portion of the main panel displays the percentage of link utilization for
the port. This information updates every five seconds. A red arrow marks the highest
utilization since the opening of the Performance View. If the system detects activity on a
port, it represents minimal activity with one bar.
When a port is logged in, moving the cursor over its bar graph displays a message with the
attached port’s WWN. If the port is an E_Port, the message reads, “E_Port,” and if the port
is not logged in, the message displays the port’s current operational state (refer to Table 3).
