86 Node List View
– Switch
– Terminal (full screen)
– Terminal (line mode)
– Unit record (input)
– Unit record (output)
– Unknown
– Unspecified
• Port WWN
The port WWN of the attached node (N_Port). The 16-digit WWN is a set of unique
numbers assigned to the device attached to the port. The WWN is prefixed by the
manufacturer’s name of the host bus adapter that attaches to the device. If there is a
nickname assigned, the nickname displays instead of the WWN.
• BB_Credit
The buffer-to-buffer credit that the attached node has available.
Click a row to select it and display the Node Properties dialog box. For an explanation
of the fields on the Node Properties dialog box, refer to Displaying Node Properties on
page 87.
Menu Options
Right-click a row to select it, highlight it, and display a menu with the following port-
related action options:
• Node Properties
Select this option to display the Node Properties dialog box. Refer to Displaying Node
Properties on page 87.
• Port Properties
Select this option to display the Port Properties dialog box (refer to Figure 26).
