66 Hardware View
Using the Port Card View
In the Hardware View, click an FPM card or right-click and select Open Port Card View to
see a detailed view of the FPM card. In the Port Card View, colored indicators reflect
functions of the actual LEDs on the card. The table in the Port Card View displays the port
operating state and vital product information.
Symbols and Indicators
The following figure illustrates the alert symbols and LED indicators that may display on a
FPM card in the Port Card View.
Figure 25 Port Card View
4
5
1
3
6
2
