Hardware View 59
Mo
ni
to
ri
n
g
a
n
d
Ma
na
g
ing
t
h
e D
ir
e
ct
o
r
• Preferred Domain ID. This is set through the Configure Operating Parameters dialog
box.
• Active Domain ID. The actual domain ID assigned to the director.
You can also display the Director Properties dialog box by right clicking the director
illustration away from a FRU and selecting Properties from the menu.
Using Menu Options
Right click on various parts of the Hardware View to display pop-up menu options for
displaying status and information and for controlling the director and its FRUs.
Director Menu
Right click on any area of the director illustration where a hardware component is not
installed to display the following menu options:
Director Properties
Click to display the Director Properties dialog box. This dialog box contains the director
name, description, location, and contact person configured through the Configure
Identification dialog box. Also included is other product information as detailed in
Displaying Director Information on page 57. You can also display this dialog box by clicking
an area on the illustration away from a hardware component.
Enable Unit Beaconing
Click the check box to toggle unit beaconing on or off. When the check box has a check
mark, unit beaconing is on, and the amber system error light on the director front bezel
blinks to help users locate the actual unit in an equipment room. When you click the check
box to remove the check mark, unit beaconing is disabled and the amber LED goes out.
Note You can only enable beaconing if there are no system errors (the system error
light is off).
