Yellow
Triangle Degraded Redundant Failure A redundant component has failed,
such as a power supply, and the
backup component has taken over
operation.
Minor Failure A failure occurred which has
decreased the director operational
ability. Normal switching operations
are not affected.
One or more FPM cards failed, but
at least one FPM card is still
operational.
A fan has failed or is not rotating
sufficiently.
One of two CTP cards failed.
One of two SBAR cards failed.
Red
Diamond
with Yellow
Backgroun
d Failed NOT OPERATIONAL A critical failure prevents the
director from performing
fundamental switching operations.
- All fans fail.
- Both SBAR cards fail.
- All installed FPM cards fail.
Gray
Square N/A Never Connected
Link Timeout
Protocol Mismatch
Duplicate Session
Unknown Network
Address
Incorrect Product Type Director status is unknown. This
occurs if the Ethernet network
connection between the HP EFC
Server and the director cannot be
established or if the CTP fails.
Refer to No Link Status on page
105 for details on the status table
text.
Table 1 Operating Status - Alert Panel and Director Status
Symbol
Alert
Panel Operator
Panel Text Director Status Table
Text
Meaning
