16 Using the Product Manager
Window Layout and Function
The main Product Manager window is divided into four main panels as shown in Figure 5:
title panel, navigation control panel, alert panel, and main panel. Use features in these
panels to configure director operation, monitor performance, and access maintenance
features.
Title Panel
The title bar identifies the current view. In Figure 5, Hardware View displays in the title
panel. Other possible views include Port List View, FRU List View, Node List View, and
Performance View.
Navigation Control Panel
The navigation control panel is the vertical panel on the left side of the window. Move the
cursor over each of the six icons in this panel to display pop-up menu options that allow
you to perform tasks related to the director. You can select options to change views on the
main panel, perform configuration tasks, and access director performance data,
maintenance tools, and online help. The following sections describe Product Manager
icons and pop-up menus.
View
Place the cursor over the View icon to display a menu that lists the five following views in
the main panel.
• Hardware
The Hardware View is the Product Manager default view.
The Hardware View is a dynamic illustration of all hardware components installed in
the front and back of the director. Operational status of the director and hardware
components is indicated by simulated light emitting diodes (LEDs) and colored alert
