HP Latex 3000 Printer - Manual (Page 301)

Table 14-3 Passes, resolutions, and speeds (continued)
Passes Ink density
Resolution (ppi)
Printing speed
(m²/h)
Printing speed
(ft²/h)
Rendering Printing 3.2 m roll 3.2 m roll
18 131–300% 600 Ч 600 600 Ч 1200 27 291
18 ≤ 130% 600 Ч 600 1200 Ч 1200 22 237
Table 14-4 Standard print modes
Print mode name Viewing distance Print mode Printing speed (m²/h) Printing speed (ft²/h)
High-saturation backlit 1–3 m 18p 6c 230% 27 290
Backlit and textile 1–3 m 14p 6c 200% 35 375
Textile and canvas 1–3 m 10p 6c 170% 44 470
Canvas and wall
covering 1–3 m 8p 6c 120% 60 630
Indoor high-quality 1–3 m 6p 6c 100% 77 830
Outdoor plus 3–5 m 4p 6c 90% 98 1050
Outdoor 3–5 m 3p 6c 80% 120 1290
Billboard > 5 m 2p 4c 70% 180 1950
NOTE: Printing speed is measured using rolls 3.2 m (126 in) wide.
Physical specifications
Table 14-5 Printer physical specifications
Weight 1500 kg (3307 lb) without crate
Width 5.979 m (235.4 in)
Depth 1.715 m (67.52 in)
Height 1.673 m (65.87 in)
Memory specifications
Table 14-6 Memory specifications for the Internal Print Server computer
Memory (DRAM) supplied 8 GB
Hard disk 500 GB
Power specifications
The drying and curing components are powered with a three-phase line that requires a power distribution
unit (PDU).
ENWW Physical specifications 295
