Parameter
{Factory setting}
Setting value / Description / Note Device Supervisor
Parameter
set
P420 … [-01]
…
… [-10]
Digital inputs
(Digital input functions)
0 … 80
[-01] = { 1 }
[-02] = { 2 }
[-03] = { 8 }
[-04] = { 4 }
all others = { 0 }
Up to 10 freely programmable digital inputs are available in the SK 54xE. Execution of the
PLC program can be stopped with the settings listed below.
[-01] = Digital input 1 (DIN1), Enable right as factory setting,
control terminal 21
[-02] = Digital input 2 (DIN2), Enable left as factory setting,
control terminal 22
[-03] = Digital input 3 (DIN3), Parameter set changeover Bit 0 as factory setting,
control terminal 23
[-04] = Digital input 4 (DIN4), Fixed frequency 1 as factory setting,
control terminal 24
[-05] = Digital input 5 (DIN5), no function as factory setting,
control terminal 25 (only available in devices size 5 and above)
[-06] = Digital input 6 (DIN6), no function as factory setting,
control terminal 26
[-07] = Digital input 7 (DIN7), no function as factory setting,
control terminal 27, (DIN7 can also be used as DOUT3)
[-08] = Digital function Analog1 (AIN1), no function as factory setting,
control terminal 14, (Digital function Analog input AIN1)
[-09] = Digital function Analog2 (AIN2), no function as factory setting,
control terminal 16, (Digital function Analog input AIN2)
[-10] = Digital input 8 (DIN8), no function as factory setting,
control terminal 7, (DIN8 can also be used as DOUT2)
Setting:
…
80 = PLC Stop: Execution of the PLC program is stopped as long as the signal is present.
P434 … [-01]
…
… [-05]
Digital output function
(Digital output functions)
P
0 … 40
[-01] = { 1 }
[-02] = { 7 }
all others = { 0 }
The digital outputs can be set by the PLC via the PLC setting.
[-01] = Binary output 1 / (MFR1), external brake as factory setting,
control terminals 1/2
[-02] = Binary output 2 / (MFR2), Error as factory setting,
control terminals 3/4
[-03] = Binary output 3 / (DOUT1), no function as factory setting,
control terminal 5
[-04] = Binary output. 4 / (DOUT2), no function as factory setting,
control terminal 7
[-05] = Binary output 5 / (DOUT3), no function as factory setting,
control terminal 27, (DOUT3 can also be used as DIN7)
Setting:
…
40 = Output via PLC: The output is set by the PLC
