Page 90
P6700, P8700& P4700 Model Group 59305, Issue 7 – March 2014
Parameter Lower
Display
Upper Display
Adjustment Range
Default
Value
When
Visible
Process High Alarm 1
value*  Range Min. to Range
Max. Range
Max.

=
 
Process Low Alarm 1
value*  Range Min. to Range
Max. Range
Min.

=
 
Deviation Alarm 1
Value*  
span from setpoint  
=
 
Band Alarm 1 value*  1 LSD to full span from
setpoint.  
=
 
Alarm 1 Hysteresis*  Up to 100% of span  Always
Process High Alarm 2
value*  Range Min. to Range
Max. Range
Max.

=
 
Process Low Alarm 2
value*  Range Min. to Range
Max. Range
Min.

=
 
Deviation Alarm 2
Value 

span from setpoint  
=
 
Band Alarm 2 value*  1 LSD to full span from
setpoint.  
=
 
Alarm 2 Hysteresis*  Up to 100% of span  Always
Set-up Lock Code  0 to 9999  Always
**First Operator mode displays follows.
Note:
Alarm parameters marked * are repeated in Configuration Mode.
Note:
**Once the complete list of Set Up Mode parameters has been displayed, the first
Operator Mode display is shown without exiting from Set Up Mode.
CAUTION:
An excessively large filter time could significantly delay detection of a limit
condition. Set this value to the minimum required to remove noise from the process
variable.
