P6010 & P8010 Indicators - Setup Mode
This mode is normally selected only after Configuration Mode has been completed, or is
used when a change to the process set up is required. These parameters must be set as
required before attempting to use the indicator in an application.
Entry into the Setup Mode
Setup Mode is entered from Select Mode
Hold down and press to force the controller into the Select Mode.
The  legend is shown for 1 second, followed by the legend for the current mode.
Press or to navigate to the Setup Mode option, then press .
Note:
Entry into Setup Mode is security-protected by the Setup Mode lock code. Refer to the
Unlock Code section for more details.
Note:
1
/
8
Din indicators have an additional Set LED . This is on in Setup Mode.
Scrolling through Parameters and Values
Press to scroll through the parameters. While this key is pressed, and up to 1
second after, the parameter legend is shown, followed by the current parameter value.
Changing Parameter Values
Press to select the required parameter, then press or to set the value as
required.
Once the displayed value is changed, it is effective is immediately. No confirmation of
the change is required.
Press to move onto the next parameter.
Hold down and press to return to Select Mode.
Note:
If there is no key activity for two minutes the instrument returns to the operator mode.
