Connections
Page 31
Option Slot 3 - Relay Output Module
If option slot 3 is fitted with a relay output module, make connections as illustrated. The relay
contacts are rated at 2 amps resistive, 240 VAC (120V max for direct Valve Motor control).
1
/
16
DIN
1
/
4
DIN &
1
/
8
DIN
Figure 27.
Option Slot 3 - Relay Module
Option Slot 3 - SSR Driver Output Module
If option slot 3 is fitted with an SSR driver output module, make connections as illustrated.
The solid-state relay driver is a 0-10V DC signal; load resistance must be no less than 500
ohms. SSR driver outputs are not isolated from the signal input or other SSR driver outputs.
1
/
16
DIN
1
/
4
DIN &
1
/
8
DIN
Figure 28.
Option Slot 3 - SSR Driver Module
Option Slot 3 - Linear Voltage or mADC Output module
If option slot 3 is fitted with a DC linear output module, make connections as illustrated.
1
/
16
DIN
1
/
4
DIN &
1
/
8
DIN
Figure 29.
Option Slot 3 - Linear Voltage & mADC module
