Universal Input Connections - Linear Volt, mV or mA input
Linear DC voltage, millivolt or milliamp input connections are made as illustrated. Carefully
observe the polarity of the connections.
1
/
16
DIN
1
/
4
DIN &
1
/
8
DIN
Figure 17. DC Volt, mV & mA Input Connections
Option Slot 1
– Relay Output Module
If option slot 1 is fitted with a relay output module, make connections as illustrated. The relay
contacts are rated at 2 amps resistive, 240 VAC (120V max for direct Valve Motor control).
1
/
16
DIN
1
/
4
DIN &
1
/
8
DIN
Figure 18. Option Slot 1
– Relay Module
