- DIN Controllers & Indicators - Product Manual
Page 168
Specifications 59305, Issue 7 – March 2014
Physical Specifications
Dimensions: Depth behind
panel: 110mm ( 1 /
16
DIN instruments).
100mm ( 1 /
8
& 1 /
4
DIN instruments).
Front bezel
size (w x h): 48 x 48mm ( 1 /
16
DIN instruments).
48 x 96mm (
1
/
8
DIN controllers).
96 x 48mm (
1
/
8
DIN indicators).
96 x 96mm ( 1 /
4
DIN instruments).
Mounting: Plug-in with panel mounting fixing strap.
Panel cut-out size (w x h):: 45mm x 45mm ( 1 /
16
DIN instruments).
45 x 92mm ( 1 /
8
DIN controllers).
92 x 45mm ( 1 /
8
DIN indicators).
92mm x 92mm ( 1 /
4
DIN instruments).
Terminals: Screw type (combination head).
Weight: 0.21kg maximum.
