Alcatel-Lucent 8950 AAA User Manual

Page 67

Policy Server tab

Managing 8950 AAA Servers

............................................................................................................................................................................................................................................................
365-360-001R6.0

Issue 1, December 2008

4-11

Database Configuration Panel

To go to the Database Configuration panel, click on the Database option from the Policy
Server data pane menu options on the left side. The Database Configuration panel is
displayed as shown in

Figure 4-8

Write Community

Specifies the write community value that controls
access to write variables. The write community has no
default values.

System Contact

Specifies the contact name of the SNMP agent.

System Name

Specifies the name of the SNMP agent.

System Location

Specifies the location of the SNMP agent.

Allow SNMP Version 1

If enabled, the policy server SNMP agent accepts
version 1.

Allow SNMP Version 2 C

If enabled, the policy server SNMP agent accepts
version 2 C.

Allow SNMP Version 3

If enabled, the policy server SNMP agent accepts
version 3.

SNMP Version 3 Engine ID

This value must be globally unique and is calculated by
the policy server upon start up using the proposed
algorithm in RFC-3411 as follows: The first four octets
of the engineID are set to the 8950 AAA enterprise
number ‘831’ with the very first bit set to 1 (8000033f),
octet number 5 is set to 01 to indicate an IPv4 address
and finally octets 6 through 9 are set the servers IP
address. This address is either the value of the server
property SNMP address, or if that address is wildcard
(*), the first non-loopback IPv4 address of the system.
Setting the SNMP V3 engine ID value explicitly will
disable the above algorithm and it is not recommended
unless absolutely necessary.

Table 4-7 SNMP properties panel–Properties

Configurable Properties

Description
