Alcatel-Lucent 8950 AAA - Manual (Page 138)

............................................................................................................................................................................................................................................................
Method Dispatch Section Using the 8950 AAA Policy Flow Editor
8-10 365-360-001R6.0
Issue 1, December 2008
............................................................................................................................................................................................................................................................
• Assign File and Method for selected row
You can perform any of the required actions using these action buttons.
Important!
Some of the necessary actions will be available with some of these
buttons. Any available actions are displayed for you to choose when you right click on
the action buttons.
1. To go to the Method Dispatch Properties panel, click the action button. The
Method Dispatch Properties panel is displayed as shown in Figure 8-12 . This panel
allows you to add or insert records to the Method Dispatch Properties.
Figure 8-12 PolicyFlow Editor–Method Dispatch Properties panel
The Method Dispatch Properties panel, as shown in Figure 8-12 , has two tabs:
• The Properties tab that allows to add a record.
• The Comment tab that allows to enter necessary comments.
By default, the Properties tab is activated and this tab allows you to enter the Method
Dispatch Properties tab details.
Table 8-13 explains each of these fields and the field descriptions that appear in the
Properties Tab of the Method Dispatch Properties Panel.
Figure 8-13 Method Dispatch Properties–Properties tab
Field Name Description
Type
Protocol Specifies the protocol: radius, diameter, USS trigger,
TACACS+, or cron.
