Stats Collector Panel

Stats Collector

............................................................................................................................................................................................................................................................
365-360-001R6.0

Issue 1, December 2008

14-3

•

The right section has two parts. The top portion displays information about the
selected group/item. It allows you to add, modify, or delete client/peer IP instance
information and allows you to change the interval for these instances and to either
enable/disable these instances.
The bottom portion displays the information about the variables for the selected
group/item. This is only for information and is read-only.

As shown in

Figure 14-2

, the statistics that you can modify or enable are categorized

according to the groups that they belong to.

The right section of

Figure 14-2

displays statistical information on Radius Acct Server and

information on the variables for the Radius Acct Server.

Use the action buttons in the top of the right section to modify the contents of the
statistical information. The function of each button is listed in

Table 14-1

Table 14-1 Stats Collector Panel–Action Buttons

Name

Description

Icon

Insert

Add a record in the current panel after the
selected row. If no row is selected, the
record is inserted at the end of the list.

Edit

Edit the values for the selected record.

Delete

Removes the selected row from the active
view.

Enable

Displays an option to either Enable the
selected instance or Enable all instances
in the view.

Disable

Displays an option to either Disable the
selected instance or Disable all instances
in the view.

Change
Interval

Allows you to set or change the interval
time for the selected instance or all the
instances in the view.
