Alcatel-Lucent 8950 AAA - Manual (Page 199)

Adding an Access Rule Configuring 8950 AAA Operators
............................................................................................................................................................................................................................................................
365-360-001R6.0
Issue 1, December 2008
11-13
............................................................................................................................................................................................................................................................
Adding an Access Rule
How to add an Access Rule
You can add an Access rule from the Operators tab. In the Operator Properties Panel, as
shown in
Figure 11-8 , click on the + or the Insert a Record action button. The Access Item
Configuration dialog appears as shown in Figure 11-9 .
Each access rule consists of three components:
• Access Type defines the type of 8950 AAA object to which this rule applies.
• File, Command, or Rule Pattern names the object or objects to which this Access Rule
applies.
• Access Level defines the type of access this System Operator has to the objects.
To add an access rule, perform the following steps:
• From the Operator Properties panel ( Figure 11-8 on page 11 ), click the button that has
+ or the Insert a record button.
Result: The Access Item Configuration dialog appears as shown in Figure 11-9 .
Figure 11-9 Access Item Configuration Dialog
8. From the Access Type drop-down list, select an access type for this rule. There are
three access types available, namely, File, Command, and Role. They are described in
Table 11-7 .
Table 11-7 Access Rules–Access Type Component
Access Type Description
File Access Type Controls access to configuration files. Also
controls access to the SMT panels that manage
data in the selected file.
Command Access Type Controls access to administrator interface
commands.
