Alcatel-Lucent 8950 AAA User Manual
Page 351
Attributes Tab
8950 AAA Dictionary Editor
............................................................................................................................................................................................................................................................
365-360-001R6.0
Issue 1, December 2008
20-7
............................................................................................................................................................................................................................................................
1. The Insert a record action button displays the Attribute Properties dialog, as shown in
. This dialog allows you to add attribute information to the dictionary.
Figure 20-7 Dictionary Editor Panel–Attribute properties dialog
The Attribute Properties dialog has a set of tabs namely, Attribute, Values, Overrides,
Aliases, and Subattributes.
The Attribute tab is the default tab.
explains the attributes of the Attribute panel
Table 20-3 Dictionary Editor–Attributes of Attributes tab
Attributes
Description
Name
Name of the Attribute to be created.
Type
Type of the Attribute.
Code
The Attribute code.
Vendor Name
Name of the Vendor.
Codec
The code encode and decoder.
Hidden
If set true, the attribute value is not displayed in the
Server Log file or Accounting Log file.
Internal
Attributes whose code is greater than 255. Used
internally within radius sever and is not be sent to NAS
