T82 Operating menu and parameter description
51
13.2 "Setup" menu
This menu contains all the parameters that are needed to configure the basic settings of the
device. The transmitter can be put into operation with this limited parameter set.
n = Stands for the number of sensor inputs (1 and 2)
Unit
Navigation Setup ® Unit
Expert ® System ® Unit
Description Use this function to select the engineering unit for all the measured values.
Options: • °C
• °F
• K
• °R
• Ohm
• mV
Factory settings °C
Sensor type n
Navigation Setup ® Sensor type n
Expert ® Sensor ® Sensor n ® Sensor type n
Description Use this function to select the sensor type for the sensor input in question.
• Sensor type 1: settings for sensor input 1
• Sensor type 2: settings for sensor input 2
Please observe the terminal assignment when connecting the individual sensors. In the case
of 2-channel operation, the possible connection options also have to be observed.
Options: A list of all the possible sensor types is provided in the 'Technical data' section (® ä 33).
Factory settings Sensor type 1: Pt100 IEC751
Sensor type 2: No sensor
Connection type n
Navigation Setup ® Connection type n
Expert ® Sensor ® Sensor n ® Connection type n
Prerequisite An RTD sensor must be specified as the sensor type.
Description Use this function to select the connection type for the sensor.
