Diagnostics and troubleshooting T82
32
Diagno
stics
number
Event text Remedial measures
Status
signal
from the
factory
Event
level from
the
factory
Changeab
le in
Diagnostics for the process
803 Current loop 1. Check wiring.
2. Replace electronics. F Alarm
842 Process limit Check the adjusted range of the analog output. M Warning 1)
F, S
925 Device
temperature Ensure ambient temperature as per specification. S Warning
F
1) Event level can be changed in: 'Alarm' or 'Warning'
11.3 Spare parts
Always quote the serial number of the device when ordering spare parts!
Type
Adapter for top-hat rail mounting, DIN rail clip as per IEC 60715
Standard - DIN securing set (2 screws and springs, 4 shaft lock-down rings, 1 plug for display interface)
US - M4 securing set (2 screws and 1 plug for the display interface)
11.4 Return
For later reuse or to return the device to the service organization of your supplier, the device must
be packed in such a way as to protect it from impact and damage. The original packaging material
offers the best protection here. When sending the unit in to be checked, please enclose a note
with a description of the error and the application.
11.5 Disposal
The device contains electronic components and must, therefore, be disposed of as electronic
waste in the event of disposal. Please pay particular attention to the local regulations governing
waste disposal in your country.
11.6 Software history and overview of compatibility
Revision history
The firmware version (FW) on the nameplate and in the Operating Instructions indicates the
device release: XX.YY.ZZ (example 01.02.01).
XX
Change to main version. No longer compatible. The device and Operating
Instructions change.
YY Change to functions and operation. Compatible. The Operating Instructions
change.
ZZ Fixes and internal changes. No changes to the Operating Instructions.
Date Firmware Version Modifications
01/11 1.00.zz Original firmware
